Powtran PI160 Series User Manual

Appendix I
127
Appendix I
under the communication mode some function code do not need to be stored and you just change
the RAM value.
If F group parameters need to achieve the function, as long as change high order F of the
function code address to 0. If E group parameters need to achieve the function, as long as change
high order A of the function code address to 4. The corresponding function code addresses are
indicated below: High byte: 00 to 0F(F group), 40 to 4F (E group), 50 to 5F(B group),60 to 67(Y
group)low byte:00 to FF
For example:
Function code F3.12 can not be stored into EEPROM, address indicates as 030C; function
code E3.05 can not be stored into EEPROM, address indicates as 4305; the address indicates that
only writing RAM can be done and reading can not be done, when reading, it is invalid address.
For all parameters, you can also use the command code 07H to achieve the function. Stop/Run
parameters section:
Stop/Run parameters section:
Parameter address
Parameter description
1000
Communication set value (-10000 to 10000) (Decimal)
1001
Runing frequency
1002
Bus voltage
1003
Output voltage
1004
Output current
1005
Output power
1006
Output torque
1007
Runing speed
1008
DI input flag
1009
DO output flag
100 A
AI1 voltage
100D
Count value input
100 E
Length value input
100 F
Load speed
1010
PID setting
1011
PID feedback
1012
PLC step
1013
High-speed pulse input frequency,Unit:0.01kHz
1014
Feedback speed, Unit: 0.1Hz
1015
Remaining run time
1016
AI1 voltage before correction
1019
Linear speed
101 A
Current power-on time
101 B
Current running time
101C
High-speed pulse input frequency,Unit:1Hz
