Powtran PI160 Series User Manual

Chapter 5 Function parameter
29
Chapter 5
5-1-5.F3 Group - Start and stop control group
No.
Code
Parameter name
Setting range
Factory
setting
Chang
e
101
F3.00
Start-up mode
0: Direct startup
1: Speed tracking restart
2: Pre-excitation start (AC
asynchronous motor)
0
☆
102
F3.01
Speed tracking mode
0: Start from stop frequency
1: Start from zero speed
2: Start from maximum frequency
3: Rotate speed tracking method3
0
★
103
F3.02
Speed tracking value
1 to 100
20
☆
104
F3.03
Start frequency
0.00Hz to 10.00Hz
0.00Hz
☆
105
F3.04
Hold time for start
frequency
0.0s to 100.0s
0.0s
★
106
F3.05
Start DC braking current
0% to 100%
0%
★
107
F3.06
Start DC braking time
0.0s to 100.0s
0.0s
★
108
F3.07
Stop mode
0: Deceleration parking; 1: Free stop
0
☆
109
F3.08
Initial frequency of stop
DC braking
0.00Hz to F0.19 (Maximum frequency)
0.00Hz
☆
110
F3.09
Waiting time of stop DC
braking
0.0s to 100.0s
0.0s
☆
111
F3.10
Stop DC braking current
0% to 100%
0%
☆
112
F3.11
Stop DC braking time
0.0s to 100.0s
0.0s
☆
113
F3.12
Braking utilization rate
0% to 100%
100%
☆
114
F3.13
Ac/deceleration mode
0:Linear acceleration and deceleration
1:Scurve acceleration and deceleration A
2:Scurve acceleration and deceleration B
0
★
115
F3.14
Proportion of S curve
start-section
0.0% to (100.0% to F3.15)
30.0%
★
116
F3.15
Proportion of S curve
end-section
0.0% to (100.0% to F3.14)
30.0%
★
5-1-6.F4 Group - V/F control parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chang
e
117
F4.00
V/F curve setting
0 to11
0
★
118
F4.01
Torque boost
0.0%(Automatic torque boost)
0.0%
★
