Powtran PI160 Series User Manual

Chapter 5 Function parameter
28
Chapter 5
87
F1.35
DI terminal valid mode
selection 1
Units digit: DI1
0: High level active
1: Low level active
Tens digit: DI2
Hundreds digit: DI3
Thousands digit: DI4
Ten thousands digit: DI5
00000
★
88
F1.36
DI terminal valid mode
selection 2
Units digit: DI6
0: High level active
1: Low level active
Tens digit: DI7
Hundreds digit: DI8
Thousands digit: DI9
Ten thousands digit: DI10
00000
★
89
F1.37
DI1 delay time
0.0s to 3600.0s
0.0s
★
90
F1.38
DI2 delay time
0.0s to 3600.0s
0.0s
★
91
F1.39
DI3 delay time
0.0s to 3600.0s
0.0s
★
92
F1.40
Define the input terminal repeat
0:Unrepeatable; 1:Repeatable
0
★
5-1-4.F2 Group - Output terminals group
No.
Code
Parameter name
Setting range
Factory
setting
Chang
e
93
F2.02
Relay 1 output function
selection (TA1.TB1.TC1)
0～42
2
☆
94
F2.04
SPA output function selection
(Collector open circuit output
terminals)
1
☆
95
F2.07
DA1 output function selection
0～17
2
☆
96
F2.11
Relay output delay time
0.0s to 3600.0s
0.0s
☆
97
F2.13
SPA output delay time
0.0s to 3600.0s
0.0s
☆
98
F2.15
DO output terminal active
status selection
Units digit:
SPB switching quantity
0: Positive logic
1: Anti-logic
Tens digit: Relay 1
Hundreds digit: Hundreds
digit: Undefined
Thousands digit: SPA
Ten thousands digit: Relay 2
00000
☆
99
F2.16
DA1 zero bias coefficient
-100.0% to +100.0%
0.0%
☆
100
F2.17
DA1 gain
-10.00 to +10.00
1.00
☆
