Powtran PI160 Series User Manual

Chapter 5 Function parameter
27
Chapter 5
1: Two-wire type 2
2: Three-wire type 1
3: Three-wire type 2
68
F1.11
Terminal UP / DOWN change
rate
0.001Hz/s to 65.535Hz/s
1.000 Hz/s
☆
69
F1.12
Minimum input value for AI
curve 1
0.00V to F1.14
0.30V
☆
70
F1.13
Minimum input setting for AI
curve 1
-100.0% to +100.0%
0.0%
☆
71
F1.14
Maximum input for AI curve 1
F1.12 to +10.00V
10.00V
☆
72
F1.15
According to F1.14
-100.0% to +100.0%
100.0%
☆
73
F1.20
Minimum input value for
panel
potentiometer
-10.00V to F1.22
0.10V
☆
74
F1.21
According to F1.20
-100.0% to +100.0%
0.0%
☆
75
F1.22
Max input value for
panel
potentiometer
F1.20 to +10.00V
4.00V
☆
76
F1.23
According to F1.22
-100.0% to +100.0%
100.0%
☆
77
F1.24
AI curve selection
Units digit: AI1 curve selection
Tens digit: AI2 curve selection
Hundreds digit: Panel
potentiometer curve selection
321
☆
78
F1.25
AI input setting selection
Units digit:
Setting selection for AI1 less
than minimum input
Tens digit:
Setting selection for AI2 less
than minimum input, ditto
Hundreds digit:
Setting selection for panel
potentiometer less than
minimum input(0 to 1,ditto)
000
☆
79
F1.26
HDI Minimum input
0.00kHz to F1.28
0.00 kHz
☆
80
F1.27
According to F1.26 setting
-100.0% to +100.0%
0.0%
☆
81
F1.28
HDI Maximum input
F1.26 to 100.00kHz
50.00kHz
☆
82
F1.29
According to F1.28 setting
-100.0% to +100.0%
100.0%
☆
83.
F1.30
DI filter time
0.000s to 1.000s
0.010s
☆
84
F1.31
AI1 filter time
0.00s to 10.00s
0.10s
☆
85
F1.33
Filtering time of panel
potentiometer
0.00s to 10.00s
0.10s
☆
86
F1.34
HDI Filter time
0.00s to 10.00s
0.00s
☆
