Powtran PI160 Series User Manual

Chapter 5 Function parameter
26
Chapter 5
49
F0.16
Ac/deceleration time
reference frequency
0: F0.19(Maximum frequency)
1: Set frequency
2: 100Hz
0
★
50
F0.17
Carrier frequency
adjustment as per
temperature
0: NO
1: YES
0
☆
51
F0.18
Carrier Frequency
0.5kHz to 16.0kHz
Depends
on models
☆
52
F0.19
Maximum output
frequency
50.00Hz to 320.00Hz
50.00Hz
★
53
F0.20
Upper limit frequency
source
0: F0.21 setting
1: AI1
2: AI2
3: Panel potentiometer setting
4: High-speed pulse setting
5: Communications reference
0
★
54
F0.21
Upper limit frequency
F0.23 (Lower limit frequency) to
F0.19(Maximum frequency)
50.00Hz
☆
55
F0.22
Upper limit frequency
offset
0.00Hz to F0.19 (Maximum
frequency)
0.00Hz
☆
56
F0.23
Lower limit frequency
0.00Hz to F0.21 (Upper limit
frequency)
0.00Hz
☆
57
F0.24
Running direction
0:Same direction
1: Opposite direction
0
☆
58
F0.26
AI analog resolution
0: 0.01Hz； 1: 0.05Hz；
2: 0.1Hz； 3: 0.5Hz
1
59
F0.27
GF type
1.G type (Constant torque load type)
2.F type (Fans/pumps load type)
-
●
5-1-3.F1 Group Input terminals group
No.
Code
Parameter name
Setting range
Factory
setting
Chan
ge
60
F1.00
DI1 terminal function selection
0 to 53
1
★
61
F1.01
DI2 terminal function selection
2
★
62
F1.02
DI3 terminal function selection
8
★
63
F1.03
DI4 terminal function selection
9
★
64
F1.04
DI5 terminal function selection
12
★
65
F1.05
DI6 terminal function selection
13
★
66
F1.06
DI7 terminal function selection
Forward running
0
★
67
F1.10
Terminal command mode
0: Two-wire type 1
0
★
