Powtran PI160 Series User Manual

Chapter 5 Function parameter
42
Chapter 5
333
E2.05
PID inversion cutoff
frequency
0.00 to F0.19(Maximum
frequency)
0.00Hz
☆
334
E2.06
PID deviation limit
0.0% to 100.0%
0%
☆
335
E2.07
PID differential limiting
0.00% to 100.00%
0.10%
☆
336
E2.08
PID reference change time
0.00s to 650.00s
0.00s
☆
337
E2.09
PID feedback filter time
0.00s to 60.00s
0.00s
☆
338
E2.10
PID output filter time
0.00s to 60.00s
0.00s
☆
339
E2.11
PID feedback loss detection
value
0.0%: Not judged feedback loss
0.1% to 100.0%
0.0%
☆
340
E2.12
PID feedback loss detection
time
0.0s to 20.0s
0.0s
☆
341
E2.13
Proportional gain KP1
0.0 to 200.0
80.0
☆
342
E2.14
Integration time Ti1
0.01s to 10.00s
0.50s
☆
343
E2.15
Differential time Td1
0.000s to 10.000s
0.000s
☆
344
E2.16
Proportional gain KP2
0.0 to 200.0
20.0
☆
345
E2.17
Integration time Ti2
0.01s to 10.00s
2.00s
☆
346
E2.18
Differential time Td2
0.000S to 10.000
0.000s
☆
347
E2.19
PID parameter switching
conditions
0: No switching
1: Switching via terminals
2: Automatically switching
according to deviation.
0
☆
348
E2.20
PID parameter switching
deviation 1
0.0% to E2.21
20.0%
☆
349
E2.21
PID parameter switching
deviation 2
E2.20 to 100.0%
80.0%
☆
350
E2.22
PID integral properties
Units digit: integral separation
0: Invalid; 1: Valid
Tens digit: whether stop
integration when output reaches
limit
0: Continue; 1: Stop
00
☆
351
E2.23
PID initial value
0.0% to 100.0%
0.0%
☆
352
E2.24
PID initial value hold time
0.00s to 360.00s
0.00s
☆
353
E2.25
Maximum deviation of twice
outputs(Forward)
0.00% to 100.00%
1.00%
☆
354
E2.26
Maximum deviation of twice
outputs(backward)
0.00% to 100.00%
1.00%
☆
355
E2.27
Computing status after PID
stop
0: Stop without computing
1: Stop with computing
1
☆
