Powtran PI160 Series User Manual

Chapter 5 Function parameter
48
Chapter 5
425
y1.27
Output terminal status of
the first fault
-
-
●
426
y1.29
Power-on time of the
first fault
-
-
●
427
y1.30
Running time of the
first fault
-
-
●
5-2.Function parameter description
5-2-1.d0 group Basic monitoring parameters
d0 parameters group is used to monitor the inverter running status information,user can view
those information through the panel to facilitate on-site commissioning,also read parameters group
value via communication for host computer monitoring.
For the specific parameters function code, name and the smallest unit , see Table 5-2.
Function code
Name
Unit
d0.00
Running frequency(Hz)
0.01Hz
Frequency inverter theory operation frequency
d0.01
Set frequency(Hz)
0.01Hz
Actual set frequency
d0.02
Bus voltage(V)
0.1V
Detected value for DC bus voltage
d0.03
Output voltage (V)
1V
Actual output voltage
d0.04
Output current (A)
0.01A
Effective value for Actual motor current
d0.05
Output power (kW)
0.1kW
Motor output torque percentage
d0.06
Output torque (%)
0.1%
Motor output torque percentage
d0.07
DI input status
-
DI input status, this value is a hexadecimal digits. The table listed each input terminal
status sequence for each bit:
0～10 bits
Input terminal status
0
Invalid
1
Valid
2
9
8
7
6
5
4
3
2
1
0
DI1
DI2
DI3
DI4
DI5
2
2
2
2
2
2
2
2
2
9
8
7
6
5
4
3
2
1
0
Reserve
DI7
DI6
Reserve
Reserve
Figure 5-1:DI input terminal status sequence
d0.08
DO output status
-
