Powtran PI160 Series User Manual

Chapter 5 Function parameter
49
Chapter 5
DO output status, this value is a hexadecimal digits. The table listed each output terminal
status sequence
for
each bit:
0～10 bits
Output terminal status
0
Invalid
1
Valid
4
3
2
1
0
Relay
SPA
2
2
2
2
2
4
3
2 1
0
Reserve
Reserve
Reserve
Figure 5-2:DO output terminal status sequence
d0.09
AI1 voltage(V)
0.01V
AI1 input voltage value
d0.11
Panel potentiometer voltage (V)
0.01V
Panel potentiometer input voltage value
d0.12
Count value
-
Actual pulse count value in counting function
d0.13
Length value
-
Actual length in fixed length function
d0.14
Actual speed
-
Motor Actual running speed display
d0.15
PID setting
%
PID Reference value percentage under PID adjustment mode
d0.16
PID feedback
%
Feedback value percentage under PID adjustment mode
d0.17
PLC stage
-
Stage display when PLC program is running
d0.18
High-speed pulse input pulse frequency (Hz)
0.01kHz
HDI(DI5) High-speed pulse input frequency display, unit: 0.01Khz
d0.19
Feedback speed
0.1Hz
Frequency inverter actual output frequency
d0.20
Remaining run time
0.1Min
Remaining run time display, it is for timing run control
d0.21
Linear speed
1m/Min
Display DI5 high-speed pulse sampling of the line speed, according to the actual sample pulse
per minute and E0.07, calculated the value of the line speed.
d0.22
Current power-on time
1Min
Total time of current inverter power-on
d0.23
Current run time
0.1Min
Total time of current inverter run
d0.24
High-speed pulse input pulse frequency
1Hz
HDI(DI5) High-speed pulse input frequency display, unit: 1hz
d0.25
Communication set value
0.01%
Frequency, torque or other command values set by communication port
d0.27
Encoder feedback speed
0.01Hz
