Powtran PI160 Series User Manual

Chapter 5 Function parameter
50
Chapter 5
Frequency set by F0.03 master frequency setting source
d0.28
Auxiliary frequency setting display
0.01Hz
Frequency set by F0.04 auxiliary frequency setting source
d0.29
Synchro rotor position
0.1%
Current position angle of synchronous motor rotor
d0.35
Command torque (%)
-
Displays inverter running status information
Data definition format is as follows:
Bit0
0: Stop; 1: forward; 2: Reverse
Bit1
Bit2
0:constant; 1:acceleration;2:deceleration
Bit3
Bit4
0: bus voltage normal; 1: undervoltage
d0.36
Inverter type
-
1:G type: Suitable for constant torque load
d0.37
AI1 voltage before correction
0.01V
d0.39
Panel potentiometer voltage before correction
0.01V
5-2-2.F0 group Basic function group
Code
Parameter name
Setting range
Factory
setting
Change
Limit
F0.00
Motor control mode
Vector control without PG
0
2
★
Reserved
1
V/F control
2
0:Vector control W/O PG
Refers to the open-loop vector control for high-performance control applications
typically ,only one inverter to drive a motor.
2:V/F control
Suitable for less precision control applications, such as fan and pump loads .One inverter
can
be used for several motors at the same time.
Note:When vector control mode , the frequency inverter and motor capacity can not be
vary widely.The AC drive’s power can be bigger than motor’s power two degree or smaller than
motor’s power one degree.If not, it may result in not very good performancecontrol ,or the drive
system does not work normally .
F0.01
Keyboard set
Frequency
0.00
Hz
～F0.19 (Maximum frequency)
50.00Hz
☆
When "Digital Setting" or "Terminal UP/DOWN " is selected as frequency source, the
parameter value is the initial value of the inverter frequency digital setting.
F0.02
Frequency command resolution
0.1Hz
1
2
★
0.01Hz
2
This parameter is used to determine the resolution of all related frequency parameters.
When the frequency resolution is 0.1Hz, PI9000 maximum output frequency can reach
3200Hz, when the frequency resolution is 0.01Hz , PI9000 maximum output frequency is
300.00Hz.
Note: when modifying the function parameters, the number of decimal places of all related
frequency parameters will change displayed, the frequency value will change accordingly.
F0.03
Frequency
source
master setting
Keyboard set frequency (F0.01, UP/DOWN can
be modified, power-down without memory)
0
1
★
Keyboard set frequency (F0.01, UP/DOWN can
1
