PPI FLOREX User Manual

OUTPUT PLUG-IN MODULES (OP2, OP3,OP4 & OP5)
The indicator supports 3 types of ‘Plug-in Modules’ that can be used as outputs (OP2, OP3, OP4 & OP5).The 3 types are; (a)
Relay /SSR Module, (b) DC Linear Voltage Module and (c) DC Linear Current Module.
5-Pin Female
Socket
4-Pin Female
Socket
Relay/SSR Module - Bottom View
Figure 12.5(a)
User Manual
FLOREX
29
Relay
SSR Drive
1 2 3 4
1 2 3 4
1 2 3 4
DC Linear
Current
(or Voltage)
1
2
3
4
1
2
3
4
1
2
3
4
Output Type Jumper Setting - B Jumper Setting - C
Table 12.1
Output-1 Jumper Settings
