24 - 2 System tour
14 SATA1/2/3 SATA connectors
15 SATA_PWR SATA power connector
16 CPU_FAN CPU fan connector
17 PCIE x 16 PCI Express x16 slot
18 SYS System power connector
19 GFX GFX power connector
20 AUXPWR_6P AUX power 6-pin connector
21 AUXPWR_8P AUX power 8-pin connector
22 LAN_USB LAN + USB 3.0 connectors
23 SS_USB USB 3.0 connectors
24 AUDIO Audio connectors
Item Code Component
