9 Master Control
The Master Control area contains an array of controls that give you access to
vital functions of the mixer including the StudioLive Series III FX rack, UCNET
communication, DAW control, and the scene library. The following section details the
use of these controls and the features they bring.
9.1 StudioLive Series III FLEX DSP Rack Effects
Your StudioLive Series III mixer is equipped with internal effects processors loaded
with models of classic reverb units, delays, and modulation effects. Each processor is
equipped with its own internal effect bus. Every channel on your StudioLive has a
send to each of these buses. Every FlexMix and the Main bus is provided with a return
from each effects bus.
Press the FX button to open the FX Rack screen on the Touch Display.
This screen displays the current effect loaded into each processor. Touching an
effect’s name will open the Effects Editor for that effects slot.
Each of the effects processors is also equipped with a physical mute button in the
Effects Master section on your StudioLive mixer.
32-Channel StudioLive models are also provided with a dedicated Tap Tempo button
in this same section. This button controls the tempo for any delay. To synchronize a
delay effect to music as you hear it, tap this button in rhythm with the music (in
1/4-note, or one-beat intervals), until the delay effect is synced to your liking.
Power User Tip: The Tap button also act as a “null” button for parameters in the Fat
Channel, Graphic EQ, and FX processors. Press and hold Tap and adjust the control of
your choice to return that control to its default setting.
