9 Master Control
9.6 Scenes and Projects
StudioLive™ Series III
Owner’s Manual
Scene Filters
Filter Name Included Parameters
Channel Info
Name
Color
Type
Input Fat Channel
Fat Channel Settings for all Inputs:
High Pass Filter
Gate Settings and Key Source
Compressor Settings and Key Source
EQ Settings
Fat Channel Order (EQ<>Comp)
Limiter Setting
Mutes On/Off state for all Mutes
Subgroup Assignments The channel assignments to every subgroup
FX Type/Settings
The active effect type for each FX Rack slot
All associated FX parameter settings
Preamp
Preamp Trim and Digital Gain
Phantom Power
Polarity
Output Fat Channel
Fat Channel Settings for all Outputs:
High Pass / Low Pass Filter
Compressor Settings
EQ Settings
Fat Channel Order (EQ<>Comp)
Limiter Setting
Main Mix Level The Main Mix output level
Aux/Matrix Mixes
The mix levels for every FlexMix configured as an Aux or a
Matrix:
Send Levels
Send Mutes
Send Pans
DCA Groups
Name
Color
Channel Type
Channels Assigned
Mix Levels (Main, FlexMixes, FX)
Channel Strip
Solo
Pan
Stereo Link
Link Options
Pre/Post Digital Send
Digital Send Source
Fat Channel A/B state
Channel Delay Input Delay settings
Main Mix Assigns The channel and subgroup assignments to the Main Mix
FX Mixes
The mix levels for every FX bus:
Send Levels
Send Mutes
Send Pans
Mute Groups
Name
Channels Assigned
Mute State
