Prestige APSRS - Page 13

APSRS_RevC_9/17
13
Output Control (Bank 3) (cont.) See page 21 for Programming Instrucon.
Detailed Descripons: Setup Opons
Feature 11: Maximum Crank Time
Funcon: Set maximum crank me for all remote start sengs.
Seng Choices:
• Opon 1 - Starter will crank for .8 seconds.
• Opon 2 - Starter will crank for 1 second.
• Opon 3 - Starter will crank for 1.5 seconds.
• Opon 4 - Starter will crank for 2 seconds.
• Opon 5 - Starter will crank for 4 seconds.
Feature 6: Start Sensing Voltage Level
Funcon: Set the sensivity of voltage variance measurement to determine if the vehicle has started when Feature 5 is
set to opon 2, Voltage.
Seng Choices:
• Opon 1 - High: Voltage dierence before remote start and aer must be greater than .5 volts.
• Opon 2 - Low: Voltage dierence before remote start and aer must be less than .5 volts.
Feature 5: Engine Conrmaon Mode
Funcon: Determine how the system knows if remote start was successful.
Seng Choices:
• Opon 1 - Determined by measurement from the Purple/White Tach Input wire.
• Opon 2 - Determined by the voltage dierence before remote start and aer as set in Bank 3, Feature 6.
• Opon 3 - Receives informaon through an aached data bus interface.
• Opon 4 - No sensing; assumes vehicle has started based on seng in Bank 3, Features 11 & 14.
Feature 9: Accessory Output Funcon (Purple)
Funcon: Set the funconality of the programmable Accessory output.
Seng Choices:
• Opon 1 - Wire sends 12-Volt (+) during ignion; drops out during start.
• Opon 2 - Wire sends 12-Volt (+) during ignion and start.
• Opon 3 - Wire sends 12-Volt (+) during start only.
Feature 7: Ignion 2 Output Funcon (Green)
Funcon: Set the funconality of the programmable Ignion 2 output.
Seng Choices:
• Opon 1 - Wire sends 12-Volt (+) during ignion and start.
• Opon 2 - Wire sends 12-Volt (+) during ignion; drops out during start.
• Opon 3 - Wire sends 12-Volt (+) during start only.
Feature 8: Ignion 3 Output Funcon (Pink)
Funcon: Set the funconality of the programmable Ignion 3 output.
Seng Choices:
• Opon 1 - Wire sends 12-Volt (+) during ignion and start.
• Opon 2 - Wire sends 12-Volt (+) during ignion; drops out during start.
• Opon 3 - Wire sends 12-Volt (+) during start only.
Feature 10: Transmission Type
Funcon: Set the funconality of the remote start system based on the vehicle transmission type.
Seng Choices:
• Opon 1 - System is set for Automac transmission.
• Opon 2 - System is set for Manual Transmission (Note: Remote Start Ready Mode must be set by the driver
before exing the vehicle.)
