Prestige APSRS - Keyless Control

APSRS_RevC_9/17
9
Detailed Descripons: Setup Opons
Keyless Control (Bank 2) See page 21 for Programming Instrucon.
1 Chirp 2 Chirp
3 Chirp 4 Chirp 5 Chirp
6 Chirp
1 Lock / Unlock Function 500ms 3.5sec
500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL
2 Ignition Lock OFF ON
3 Ignition Unlock OFF Unlock All
Unlock Driver
4 Exterior Illumination OFF With Arm
With Disarm With Arm & Disarm
5 Auto Relock OFF ON
6 Auto Arming / Locking NA
7 Notification Sound NA
8 Horn Timing 16ms 30ms
40ms 50ms 10ms
9 Valet Override Method NA
10 Driver Priority Unlock OFF ON
11 Silent Choice OFF From Transmitter
OEM Style
12 Security Profile OFF OEM Security
13 Door Trigger Input Negative Positive
14 Park Light / Trunk Swap OFF ON
15 Data Port Protocol ADS DBI
Feature Bank 2
Options
Features
Feature 1: Lock / Unlock Funcon
Funcon: Set the lock / unlock output ming and funconality for specic vehicle lock types.
Seng Choices:
• Opon 1 - Lock and Unlock outputs will pulse for 500 milliseconds.
• Opon 2 - Lock and Unlock outputs will pulse for 3.5 seconds.
• Opon 3 - Lock output will pulse for 500ms ; Unlock output will pulse twice, 500ms each.
• Opon 4 - Lock output will pulse twice, 500ms each ; Unlock output will pulse for 500ms.
• Opon 5 - Lock and Unlock outputs will pulse twice for 500ms.
• Opon 6 - Lock output will pulse for 500ms ; Unlock output will pulse for 350ms.
Feature 2: Ignion-Acvated Lock
Funcon: Set the door locks to lock when brake is pressed aer the ignion is turned ON.
Seng Choices:
• Opon 1 - Doors do not lock with ignion.
• Opon 2 - Doors Lock when brake is pressed aer ignion on.
Feature 3: Ignion-Acvated Unlock
Funcon: Set the door locks to unlock when the ignion is turned o with the key.
Seng Choices:
• Opon 1 - Doors do not unlock with ignion o.
• Opon 2 - All Doors Unlock with ignion o.
• Opon 3 - Driver Door Unlocks with ignion o.
Feature 4: Exterior Illuminaon
Funcon: Set the parking lights and head lights to remain on for 30 seconds when the doors are locked or unlocked
with the remote control.
Seng Choices:
• Opon 1 - The lights will funcon normally.
• Opon 2 - The lights will remain on for 30 seconds when the doors are locked with the remote control.
• Opon 3 - The lights will remain on for 30 seconds when the doors are unlocked with the remote control.
• Opon 4 - The lights will remain on for 30 seconds when the doors are locked or unlocked with the remote
control.
