Quick Reference: Wiring Diagrams
Door Lock Connecons
Single-Wire Negave Mulplex Door Locks (Relays required)
Vericaon: The vehicle wire registers variable Ground values when the Lock and Unlock switches are acvated. Please
consult the vehicle-specic wire and locaon chart for resistor values.
Single-Wire Posive Mulplex Door Locks (Relays required)
Vericaon: The vehicle wire registers variable 12V+ values when the Lock and Unlock switches are acvated. Please
consult the vehicle-specic wire and locaon chart for resistor values.
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output
Green ( - ) Unlock Output
87
87a
86
30
87
87a
86
30
85
85
Fused +12 Volt
Baery Source
Ground
Resistor
Lock
Unlock
Vehicle Door Lock
Control Relays
RED ( - ) Lock Output
Green ( - ) Unlock Output
87
87a
86
30
87
87a
86
30
85
85
Fused +12 Volt
Baery Source
Resistor
