42 Label and Roll Specifications
Max Min
Label/Print width 108mm (4.25") 19mm (0.75")
Liner width 108mm (4.25") 25.4mm (1")
Label height/length 609.6mm (24") 19mm (0.75")
Gap between labels 19mm (0.75") 2.5mm (0.10")
Width of thru-hole opening 12.7mm (0.5") 9.5mm (0.375")
Distance from edge of media 48.3mm (1.90") 5.1mm (0.20")
to edge of thru-hole
Reflective/Black Mark Width* Equal to distance 2.5mm (0.10")
between labels
Max Outer Diameter (OD) 127mm (5.0") N/A
Inner Core Diameter (ID) see roll specifications below
Stock Thickness** 10 mil (.0010”) N/A
Distance from edge of media to Printer driver assumes 2mm gap. edge of
label However, this is adjustable via the
left margin offset.
* The Reflective/Black Mark should be opaque to infared light. The mark
should be between the labels. The end of the mark should correspond with
the beginning of the next label.
**This is the recommended maximum. There are two factors that determine
whether the printer will accept any particular stock thickness.
1. The ability for the printer to pull the paper through the print area.
2. The ability for the sensor to read through the backing if the sensor is set to
die-cut.
If you are printing in continuous or reflective label sensing mode number 2
does not apply. The fact that the printer must read through the backing in
die-cut mode will limit the thickness much more than the printer's ability to
pull the paper through the print area. However, if you adjust opacity level of
the liner enough to allow the label to be seen by the stock sensor, the
thickness will only be limited by the printer's ability to pull it through the
printer area. For these reasons the weight or thickness of the liner is a
variable that can not easily be defined. Primera recommends and uses 40#
liner with all label stock.
