540876_A_PUB_DATE_1_FEB_2012.DOC PROGRAMOVACÍ MANUÁL 41
PROGRAMMING
Prewash
Wash
Cooldown
Rinse
Last Rinse
Soak
S
ra
No wash
THE WASH SEQUENCE
Menu Item Default Info Limits
Temperature 60 °C The water temperature.
1 - 92 °C
Inlet I2-I3-I6-I8 The suggested inlet valves are related to the
temperature and the soap box to be used.
Attention!
If you insert other inlet valves than the suggested ones,
problems can occur at the water fill process.
I1...I8
Level Normal
Low
The suggested water level depends on the machine
Type.
See table 3.5.A
RPM - The suggested RPM depends on the machine Type. See table 3.5.B
Detergents Menu…
Supply 1, …, 8
0 sec
Time selection for Soap Boxes (hopper) and external
liquid soap supplies.
You can program up to 4 supplies at the same time.
If you have programmed more then 4 supplies an error
message will be generated. Put the time of the
supplies back to zero until not more than 4 non-zero
time values are remaining.
(Liquid soap supplies must be switched on at the configuration
Menu)
0 - 99 sec
On Time 12 sec The wash action, motor On Time.
Gentle wash action : 3 sec.
(The suggested default values can be adjusted at the Initialization
menu)
1 - 99 sec
Off Time 3 sec The wash action, motor Off Time.
Gentle wash action : 12 sec.
(The suggested default values can be adjusted at the Initialization
menu)
1 - 99 sec
Time 7.0 Min The Wash Sequence Time.
(for 0 Minutes the Wash sequence will be skipped)
(programmable in steps of 0,5 Minutes)
0 - 99.5 Min
Signal No When a signal is programmed, a pause will be
introduced at the end of the Wash Step. This allows
the operator to add soap for the next step. A buzzer
signal warns the operator that the cycle has been
interrupted.
No / Yes
!
