GP3000 Series Hardware Manual
4-10
 Cable Attached Dimensions
Unit: mm[in.]
• All the above values are designed in case of cable bending. The dimensions given
here are representative values depending on the type of connection cable used.
Therefore, they are all intended for reference only.
Rear
Right side
83[3.27]
Left side
Bottom
83[3.27]
106[4.17]
84[3.31]
70[2.76]
