2.
Page 2-1
Orion Machine Manual
Revision 3.0 CTS Flex Stretchwrapper
25 July 2016 System Description
System Description
Machine Specifications
Utilities
• 115 / 1ph / 60hz 20 Amp Service
Standard Speed
• 16 Rpm Variable Turntable Speed Vfd Controlled Motor**
Features
• Orion Model Flex CTS Conveyorized Two Station Automatic Stretch Wrapping
Machine (available in various flow direction/ conveyor configurations)
• Powered CDLR roller turntable
• Conveyor speed up to 30 FPM
• Heavy Duty Chain Drive
• Electronically Adjustable Acceleration/deceleration And Running Speeds (At Vfd)
• Positive Alignment Feature (True Home Position)
Control Features
• Nema 12 Control Panel
• User Friendly Interface with Graphical Maintenance Reminders
• IP Address is Modifiable for Networking
• Easy to Use Icon Based Interface
• Web-based Production Data Dashboard
• Optional Wireless Connection to the PLC/ HMI
• Downloadable VFD Parameters
• Variable Speed Film Carriage Up/ Down Control
• Film Carriage Manual Jog Functionality
• Photocell For Automatic Load Height Detection
• Main Drive Jogging
• Variable Speed Main Drive
• Semi-automatic Reinforce Wrap Feature
• On-Screen Interactive Troubleshooting Guide
