Engineering Information (Continued):
Operator Interface Panel (OIP) (Continued):
Main Menu (Continued):
Main Menu Information
Panel
Description
OUTLET TEMPERATURE
Displays the temperature measured from the process sensor located
at the outlet of the heater.
HEATER OUTPUT
Displays the output load of the heating elements needed to provide
the desired outlet temperature.
HEAT ON/OFF
This button will start or stop heater operation. The field directly
above this button displays the current status of this selection.
ALM. LOG
This button will display the ALARMS SUMMARY screen.
CONFIG
This button will display the CONFIGURATION MENU screen.
ALARMS
This button will display the ALARMS MENU screen.
