Process Technology Lufran LUF Series - Spare Parts; Spare Parts List Common to all Units

58
M-43-25 LUF-Series Lufran Manual
Revision - Date 03-01-04-18 Standard outlet, Standard Interface
Spare Parts:
Listed below is the spare parts list for the LUF-series Lufran fluoropolymer inline water heater. These are
items that may need replacement after some time in service. This is not the complete parts list, so there
are some heater components that are not listed below. Please contact PROCESS TECHNOLOGY if a
more complete parts list is needed.
Spare Parts List Common to all Units:
Process
Technology
Part #
Description Qty
13192
POWER SUPPLY, 24VDC, 240W
1
13205
OPERATOR INTERFACE PANEL,
COLOR 6" SCREEN
1
10937
POWER ON SWITCH ASSEMBLY
(pushbutton, light, base, contact block)
1
10938
POWER OFF SWITCH ASSEMBLY
(pushbutton, light, base, contact block)
1
10939
EMO SWITCH ASSEMBLY
(pushbutton, light, base, contact block)
1
7383
RELAY: SSR, 15Amps, 50VDC
1
8986
RELAY: SSR Module, 125Amps, 600VAC
(One per heating column 24
-52kW
(heat sink, two SSRs, overtemp thermostat, cooling fan, guard)
1
4851
Alarm, Sonalert audible buzzer
1
9289
FAN: Cabinet Cooling Fan, 24 VDC
2
9961
HUMIDISTAT: HUMIDITY CONTROL
1
TC-L-KT-2.25
SENSOR: Inlet/outlet water temperature, J-type thermocouple
2
3947
FUSE: 10A, 600V
4
Additional Spare Parts for Specific Units:
Process
Technology
Part #
Part for the
Following
Wattage
Units:
Description Qty
**
FUSE: high voltage power distribution
(Refer to page 1 of the electrical prints for the specific part
number of these fuses.)
3
**
HEATER: replacement heating column
(Refer to label on heating column for the specific model
number of this part)
1
TC-L-KT
Up to 52kW,
105kW
SENSOR: heating column water temperature, J-type
thermocouple, one sensor per column
1
TC-L-KT-15
65kW,
72kW,
78kW,
>130kW
SENSOR: heating column
water temperature, J-type
thermocouple, one sensor per column
1
