ProFire PF2100 - Common Applications & Optional Hardware; System Diagram

98
POWER CONSUMPTION 12V 24V
Controller only, display ON 2.6 W 2.9 W
Controller only, display OFF 1.1 W 1.2 W
Maximum Total Current Draw 5A 5A
Maximum Valve Current Draw 2A 2A
Ignition Voltage (Internal Coil) up to 20 kV up to 40 kV
TERMINAL BLOCKS VALUE
Maximum Wire Gauge 12 AWG
STATUS CONTACT VALUE
Type Dry
MAX Voltage 40VDC
MAX Continuous Current 250mA
Impedance (When Closed) 15Ω
PHYSICAL DIMENSIONS VALUE
Width 30.9 cm (12.15 in)
Height 23.4 cm (9.23 in)
Depth 13.4 cm (5.28 in)
WEIGHT VALUE
E0000 Model 4.0lbs / 1.8kg
E0400 Model 4.5lbs / 2.0kg
E0M00 Model 4.5lbs / 2.0kg
EC000 Model 6.0lbs / 2.6kg
E0R00 Model 4.5lbs / 2.0kg
FUSES VALUE
Main Fuse Rating 5A / 250 V Ceramic, Fast Blow
Status Contact Fuse Rating 250mA / 125V Ceramic, Fast Blow
Replacement Main Fuse LittelFuse 0314005.HXP
Replacement Status Contact Fuse LittelFuse 0453.250 or 0451.250
1.6 | Common Applications & Optional Hardware
Below are examples of some of the many applications that the PF2100 can be used in.
Line Heater
Dehydrator
Combustor
Tank Heater
Separator
Treater
Gas Production Unit
Amine Reboiler
Thermal Oxidizer
Depending on your installation type, other components may be required. Commonly requested hardware
includes:
Mounting Hardware
Channel Bar
Conduit Ports
Liquid Tight Ports
Rubber Grommets
Wire
Ignition Wire
Thermocouple Wire
Rods And Connectors
Kanthal Ignition Rods (Various Lengths)
Valves
DC Solenoids
Safety Valves with Proof of Closure
Proportional Valves
Thermocouples
Single, Type K
Dual Element, Type K
Pilot Assembly
Nozzles
Brackets
Mixers
Orifices
Autonomy
Batteries
Solar Chargers
Solar Panels
Accessories
Modbus Expansion Cards
4-20mA Repeater Expansion Cards
Data Logging Expansion Cards
External Ignition Coil
Please contact Profire Sales for further information.
1.7 | System Diagram
