PROLiNK PRC2401U - 5 Technical Specification

PROLiNK® PRC2401U Wireless AC2600 MU-MIMO Dual-Band Gigabit Router
74
5 Technical Specification
Specifications
WiFi Standard
• Concurrent Dual-Band; IEEE 802.11b/g/n (2.4GHz);
• IEEE 802.11a/n/ac (5GHz)
Frequency
• 2.4GHz/ 5GHz
Data Rate
• 800Mbps (2.4GHz); 1733Mbps (5GHz)
Operation Mode
• Router Mode/Access Point (AP) Mode/Repeater Mode
Security
• 64/128-bit WEP, WPA-PSK/WPA2-PSK, Mac Address Filter , Wi-Fi
Protected Setup (WPS)
Firewall
• Firewall, Web Filtering, Parental Control, DMZ, Port Forwarding
Interface
• WAN x 1: 10/100/1000Mbps Gigabit Ethernet Port (RJ45)
• LAN x 4: 10/100/1000Mbps Gigabit Ethernet Port (RJ45)
• USB3.0 x 1
Buttons
• Power, WPS, Wi-Fi ON/OFF, Reset
Antenna
• 4 x Fixed External High-Gain Antenna
Power Adapter
• 12VDC/2A
Power
Consumption
• 24W (Maximum)
Dimension
• 220 x 154 x 40 mm (Product Only)
• 319 x 273 x 75 mm (With box)
Warranty
Refer to Service Policy and Warranty
