Estimating Cartridge Life
Estimating how long a cartridge will last and the number of days between services is critical to
performing an installation that can be serviced efciently. This includes determining the number of
AQ1570 cartridge heads needed for a space. Please refer to AirQ’s ‘S3 (Sizing, Service & Success)
Tool,’ available at ProlitecCSPTools.com. The chart below can be used as a rough guideline for sizing.
Room-Size Table
Normal Off-Cycle
(NOC)
Short Off-Cycle
(SOC)
Very Short Off-Cycle
(VSOC)
Output
Level
Range
Room Volume Range Room Volume Range Room Volume Range
CFT CM CFT CM CFT CM
1-5 1800-8100 51-229 6000-25000 170-708 21400-66700 606-1888
6-10 10000-17400 283-492 30000-47100 849-1333 75000-97100 2123-2748
11-15 19300-27700 546-784 51100-66300 1446-1876
101100-
114000
2861-3226
16-20 30000-39700 849-1124 70000-83600 1981-2366
116700-
125100
3303-3540
21-25 42300-53400 1197-1511 86800-98900 2456-2799
126900-
132800
3591-3758
26-30 56300-68600 1593-1941 101600-112700 2875-3170
134000-
138300
3792-3914
31-35 71800-812700 2032-2425 114400-123500 3238-3495
139200-
142400
3939-4030
36-40 89400-104800 2530-2966 125600-133600 3554-3781
143100-
145500
4050-4118
41-45 108900-126200 3082-3571 135400-142300 3832-4027
146100-
148000
4135-4188
46-50 130700-150000 3699-4245 143900-150000 4072-4245
148400-
150000
4200-4245
These settings are suggested as a starting point. Start on the lower end of the range and adjust after
one hour. Fragrance type, room size, number of fresh air changes per hour, temperature, humidity
and user preference will determine the nal setting. Best practice is to use AirQ’s ‘S3 Tool’ at
ProlitecCSPTools.com.
5

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
