Prolitec AirQ 1570 User Manual

AQ1570 2
Contents
Chapter 1: IMPORTANT SAFETY
INSTRUCTIONS
Appliance Precautions
Fragrance Cartridge Precautions
Chapter 2: About AQ1570
Chapter 3: Unpacking
Chapter 4: MOVING AND STORAGE
INSTRUCTIONS
Chapter 5: INSTALLATION
General
Location
Service Area
Estimating Cartridge Life
Room-Size Table
Appliance Location
Wall Mounting AQ1570
Installation Kits
CCU Installation
Cartridge Unit Installation
Airline Tubing Installation
Installing an Additional Module
Chapter 6: OPERATING INSTRUCTIONS
Features and Controls
Setting Up the Cartridge
Programming the Appliance
Using the Online SD Card
Programming Tool
Setting Scent Intensity
Scent Control
Chapter 7: USER MAINTENANCE
Cartridge Change
Cartridge Change Maintenance Checklist
Items
Changing an Appliance
General Care
Chapter 8: Applications
Ambient Scenting
Product Marketing
Odor Control
Aromatherapy and Performance Scenting
Chapter 9: Frequently Asked Questions
Chapter 10: Specications

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
