AQ1570 22Chapter 6 OPERATING INSTRUCTIONS
Setting Scent Intensity
1. Determine the approximate size of the room in cubic feet or cubic meters by multiplying length
x width x ceiling height.
2. Consult the Room-Size Table to give you a level (1 to 50) to set. THIS IS ONLY A STARTING
POINT.
Hint: There are many variables to nding the scent level
that works: size, airow, number of fresh air changes per
hour, number of people in the space and, most of all, user
preferences. Experiment with different levels until you are
satised. Utilize the S3 Tool.
Scent Control
If you followed the Room-Size Chart or S3 Tool, you have set AQ1570 to the low end of the range for
your room size. If after one hour you feel the scent is not detectable, increase the setting by about
10%. For example, if your start setting was 20, increase it by 10%, or to setting 22. Keep increasing
until you and others in the space can detect a slight scent throughout the space.
The Last Step
1. Set the appliance to either 24/7 or Run Program.
2. Make sure the power is on.
3. Close and lock the door, storing the key in a known place.
6

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
