AQ1570 8Chapter 4 MOVING AND STORAGE INSTRUCTIONS
MOVING AND STORAGE INSTRUCTIONS
AQ1570 Central Control Unit (CCU)
1. Unplug the appliance.
2. Disconnect the airline tubing.
3. Unscrew and remove the long round-head screws in the upper and lower corners.
4. Remove the appliance from the wall.
5. Store at -4° F (-20°C) to 158° F (70°C), 5% to 95% humidity.
AQ1570 cartridge head
1. Remove the cartridge and plume kit.
2. Disconnect the airline tubing.
3. Unscrew and remove the long round-head screws in the upper and lower corners.
4. Remove the enclosure from the wall.
5. Store at -4° F (-20°C) to 158° F (70°C), 5% to 95% humidity.
4

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
