Prolitec AirQ 1570 User Manual

AQ1570 24Chapter 7 USER MAINTENANCE
Changing an Appliance
Appliance malfunctions are not intended to be serviced in the eld, however the inner module is
eld replacable. If there is no plume after following the procedure outlined above, contact Customer
Care.
General Care
• AQ1570 is an electronic appliance. Treat it like a laptop.
• Do not place or store AQ1570 or its cartridges in extreme heat (more than 130˚ F) or in freezing
temperatures.
• Do not drop AQ1570 on the oor. Do not drop it in or position it near water.
• Do not paint or otherwise try to alter the color of the outer cover.
• When shipping, pack in the original box and place it in an outer cardboard box.
• Always keep the plugs in cartridges when not in use.
Always remove the cartridge from the appliance before moving
it anywhere. Otherwise leakage can occur, destroy the unit and
the warranty is voided.
7

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
