Prolitec AirQ 1570 User Manual

AQ1570 9Chapter 5 Installation
Installation
General
Location
The AQ1570 CCU is designed for permanent installation on wall surfaces near a 100-240V outlet. The
AQ1570 cartridge head is designed for permanent installation on a wall surface.
Service Area
The service area range of each AQ1570 cartridge head is from 1,800-150,000 cubic feet (51-4245
cubic meters). Of course this can vary signicantly depending on airow, number of fresh air changes
per hour, temperature, humidity and desired service interval. AQ1570 can be adjusted from 1 to 50
to accommodate these variations. The AQ1570 CCU must be within 100 feet (30.48 meters) of all
associated cartridge heads.
Conguration
The AQ1570 CCU must be wall mounted near a 100-240V power source. The CCU can control up to four
cartridge heads, which must be wall mounted within a 100-foot (30.48-meter) distance from the CCU.
Each cartridge head package contains 50 feet (15.24 meters) of airline tubing, and additional 50-foot
(15.24-meter) tubing segments are available for separate purchase. Extra tubing length can be cut or
coiled during installation. Tubing lengths beyond 100 feet (30.48 meters) are not recommended.
5

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
