Prolitec AirQ 1570 User Manual

AQ1570 18Chapter 6 OPERATING INSTRUCTIONS
Programming the Appliance
1. Unlock and open the door of the CCU.
2. Turn on the power by pressing : on the control panel.
3. Set the Clock.
• Press I to cycle through the modes to the options mode. The day of the week will blink.
• Adjust the day forward or backward using E or F.
• Press L to set the day of the week and the hour will blink.
• Adjust the hour forward or backward using E or F.
• Press L to set the hour and the minute will blink.
• Adjust the minute forward or backward using E or F.
• Press L to set the minute and the hour and minute will both blink.
• Change between 24-hour and 12-hour modes using E or F.
• Press L to set the time mode and the off-cycle will blink.
• Change between normal (NOC, 7 minutes), short (SOC, 2 minutes), and very short (VSOC, 30
seconds) modes using E or F.
• Press L to set the off-cycle and the fan setting will blink.
• Adjust the fan speed up or down using E or F.
• Press L to set the fan speed and the day of the week will blink.
4. 24/7 Mode.
• If you want AQ1570 to run continuously — 7 days a week, 24 hours a day — press I until
24/7 is displayed above the time. If not, skip to Step 5.
5. Set Program Mode.
• Press I until Set Program is displayed above the time. The program number will blink in the
lower right corner of the display
• Adjust the program number forward or backward using E or F.
• Press L to set the program number and the status will blink.
• Adjust the status between on (“on”) and “off” (“oF”) using E or F.
• Press L to set the status and the intensity will blink.
• Adjust the intensity up or down using E or F.
6

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
