Prolitec AirQ 1570 User Manual

AQ1570 23Chapter 7 USER MAINTENANCE
USER MAINTENANCE
Cartridge Change
When the reservoir is empty the cartridge needs to be changed. The change process is simple. Best
practice is to wear gloves when manipulating the cartridge.
1. Unlock and open the doors of the CCU and cartridge enclosures.
2. Turn off the power by pressing the power button.
3. Grab the cartridge and disconnect air stem and plume kit.
4. Inspect the air stem seal for damage. Replace if damaged.
5. Remove plugs from new cartridge and use them to plug empty cartridge.
6. Deliver empty cartridge to recycling center at a later date.
7. Connect new cartridge to air stem and plume kit, and seat in appliance.
Cartridge Change Maintenance Checklist Items
Cartridge plume: Use a high-intensity ashlight or your headlamp to conrm that a plume is
streaming from the output port. If there is no plume:
• Check that the power is on and the appliance is running.
• Check that the wipers on the air stem are in place and not cracked or broken. Replace if
necessary.
• If the appliance is set to Run Program, switch it to 24/7 and check for a plume.
• If no plume, set it back to Run Program and change the cartridge.
• If still no plume, try another cartridge just to make sure. If no plume, replace the appliance. (See
Changing an Appliance).
• Wipe the unit clean inside and out.
7

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
