AQ1570 21Chapter 6 OPERATING INSTRUCTIONS
3. Press the reset button, and the ve buttons will light in sequence from left to right.
4. The : and E buttons will light alternately.
5. Press and hold : for one second, and the display will show LOAD for about ten seconds.
6. The ve buttons will light in sequence from left to right.
7. Remove the SD card; the display will show the currently loaded rmware version and the pump
will run for one second.
8. Press : to turn on the power.
9. Press I to cycle through the modes to the Run Program mode.
10. Press L to view the start time for the rst program.
11. Press L again to view the stop time for the rst program.
12. Press E or F to view the second and third programs.
13. Be sure the power is on and the appliance is in Run Program mode prior to closing and locking
the door.
Copying programs to an SD card
1. Insert a FAT32 formatted SD card, with the label side down.
2. Press the reset button, and the ve buttons will light in sequence
from left to right.
3. The : and E buttons will light alternately.
4. Press and hold E for one second, and the display will show SAVE for
about ten seconds.
5. The ve buttons will light in sequence from left to right.
6. Remove the SD card; the display will show the currently loaded rmware version and the pump
will run for one second.
7. Press : to turn on the power.
8. Be sure that the power is on and the appliance is in Run Program mode prior to closing and
locking the door.
9. The new le created on the SD card will be called “outsche.txt.” Changing it to “schedule.txt”
allows the programs to be loaded on another appliance.
6

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
