AQ1570 20Chapter 6 OPERATING INSTRUCTIONS
• Programs sets need to be saved.
3. Edit an existing program set using the edit button to the right of the program name.
4. Copy an existing program set using the copy button to the right of the program name. This can
be especially useful for quickly duplicating a very similar set of programs.
5. Delete an existing program set using the delete button to the right of the program name.
6. Export an existing program set using the export button to the right of the program name.
• A .zip le containing your program set (schedule.txt), the latest rmware (discover.hex), and
the nal instruction for use (readme.txt) will download to your computer.
• Insert an SDHC card and format it FAT32.
• Copy the les needed (schedule.txt for programs, discover.hex for rmware) to the top level
directory of the card (not in a folder or .zip le).
7. Insert the SD card into the appliance, with the label side down.
Loading new rmware from an SD card
1. Copy discover.hex to a FAT32 formatted SD card.
2. Insert the SD card, with the label side down.
3. Press the reset button, and the ve buttons will light in sequence
from left to right.
4. The : and E buttons will light alternately.
5. Press and hold : for one second, and the display will show LOAD for
about ten seconds.
6. The ve buttons will light in sequence from left to right.
7. Remove the SD card; the display will show the currently loaded rmware version and the pump
will run for one second.
8. Press : to turn on the power.
9. Be sure that the power is on and the appliance is in Run Program mode prior to closing and
locking the door.
Programming the Appliance from an SD card
1. Copy schedule.txt to a FAT32 formatted SD card.
2. Insert the SD card, with the label side down.
6

Prolitec AirQ 1570 Specifications

Power

input voltage	100 – 240V AC
input current	1.5A max
frequency	50/60 Hz
internal power	15VDC at 4 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less
service area per cartridge head	Up to 150, 000 cu. ft. (4245 m³)

Capacity

liquid capacity	2500mL cartridges

Weight and Dimensions

CCU dimensions	36cm x 35cm x 17.2cm
cartridge head dimensions	35.6cm x 18cm x 17.2cm
CCU weight with 4 modules	12 lbs (5.1 kg)
cartridge head weight	5 lbs (2.5 kg)
