Prolon VC2000 Series - Page 35

PL-M2000-FLX (FlexIO Controller)
INT Port : Incoming RS485
Network Communication
(modbus)
Analog Output 3
Analog Output 2
Analog Output 1
Digital Output 5
Digital Output 4
Digital Output 3
Digital Output 2
Digital Output 1
Analog Input 9
Analog Input 8
Analog Input 7
Analog Input 6
Analog Input 5
Analog Input 4
Analog Input 3
Analog Input 2
Analog Input 1
M2000-RTU
M2000-HP
M2000-HYD
C1050-RTU
C1050-HP
NC2000
Outside Temperature (optional)
9 Dierent Schedules (optional)
Outside Temperature
Occupancy
Supply Air Temperature
Math Values
Fan Status
24
VAC
Bottom Row:
Common for all outputs
Bottom Row:
Common for all inputs
Controller’s power source
24 VAC
NET Port: Incoming RS485 Network
communication (Modbus)
4-14
