Conguration 2: Using Maximum Cooling/Heating Functions
• Select Math 1 as “Maximum Cooling”
• Select Math 2 as “Maximum Heating”
Math 1= Maximum (-25;-35;-45;-100;-100) = -100%
Math 2= Maximum (100;100;75;10) = 100%
Conguration 3: Using Weighted Average Functions
• Select Math1 as “Weighted Average”
The following is how the math functions are calculated
1+1+2+1+1+2+1+1+1+2
Math 1 = = - 3 3.1%
(-25×2)+(-35×1)+(-45×1)+(-100×1)+(-100×2)
Math 2 = = 27.7%
1+1+2+1+1+2+1+1+1+2
(100×1)+(100×1)+(75×2)+(10×1)
Math 1 = = -5.4%
1+1+2+1+1+2+1+1+1+2
(100×1)+(100×1)+(75×2)+(10×1)+(0×1)+(-25×2)+(-35×1)+(-45×1)+(-100×1)+(-100×2)
Conguration 1: Using Weighted Average Functions (Cooling/Heating only)
• Select Math 1 as “Weighted Average (Cooling only)”
• Select Math 2 as “Weighted Average (Heating only)”
