ProMinent Beta BT4b - Beta 0232 SS liquid end

1
1
5
8
6
7
2
2
3
P_BE_0028_SW
Fig. 38: Beta
®
0232 SS liquid end
Pos. Description Type 0232
1 Connector kit 12 mm SS 104245
3 4 Valve balls 404281
5 Discharge valve compl. 12 mm SST 809446
6 Diaphragm 1000251
7 Safety diaphragm 1027414
8 Suction valve compl. 12 mm SST 809447
Spring (pos. 2)
is a special accessory. The positions listed are included in the spare parts kit. We reserve the
right to make technical modifications.
Beta
®
0232 SS liquid end
