4
2
1
5
3
13
P_SI_0038
Fig. 36: Cross-section through the liquid end
1 Suction valve
2 Diaphragm
3 Discharge valve
4 Dosing head
5 Backplate
13 Safety diaphragm
Carrying out repairs
78
