15.5.2 Media temperatures
Data Value Unit
Max. temperature long-term at max. oper‐
ating pressure
65 °C
Max. temperature for 15 min at max. 2 bar 100 °C
Minimum temperature -10 °C
Data Value Unit
Max. temperature long-term at max. oper‐
ating pressure
90 °C
Max. temperature for 15 min at max. 2 bar 120 °C
Minimum temperature -10 °C
15.5.3 Air humidity
Data Value Unit
Maximum air humidity*: 95 % relative
humidity
*non-condensing
15.5.4
Degree of Protection and Safety Requirements
Protection against contact and humidity:
IP 65 in accordance with IEC 529, EN 60529, DIN VDE 0470 Part 1
A CAN plug or the supplied sealing cap must always be
plugged into the CAN port for the HMI.
Degree of protection:
1 - mains power connection with protective earth conductor
15.6 Installation height
Data Value Unit
Maximum installation height*: 1000 m above
standard
zero
* with standard pumps: Fit at higher installation heights at your own risk.
with ATEX pumps: We urgently advise that you contact a specialist for
ATEX motors at higher installation heights!
PVT liquid end
SST liquid end
Air humidity
Degree of protection
Safety Requirements
Technical data
88
