15.7 Electrical connection
The electrical data do not relate to the motor, but the
pump, which is connected as a whole unit.
For the motor electrical data, use the motor data sheet
from our website www.prominent.com.
Identity code specification "power supply" - "U": 100 - 230 V ± 10%, 240 V
± 6%, 50/60 Hz
Data Value Unit
Capacity 220 W
Max. starting current 8.5 A
Electrical data at 100 V
Data Value Unit
Effective current 3.3 A
Switch on peak current, (for approx. 100
ms)
4 A
Electrical data at 230 V
Data Value Unit
Effective current 1.5 A
Switch on peak current, (for approx. 100
ms)
8 A
* internal switchover
Fuses
Fuse Value Order No.
Fuse, internal 6.3 AT - (1.5 kA) 732379
Only use the original fuses from ProMinent! It is not suffi‐
cient to use a fuse with the above fuse rating.
15.8 Diaphragm rupture sensor
Contact loading, max.
at voltage Maximum current
30 V DC 1 A
The contact is an opener.
The contact is an potential-free.
Electrical data S2Cb pump
Contact (standard)
Technical data
89
