Promise Technology VTrak J310S User Manual

Chapter 2: Installation
21
Figure 15.I/O modules have a circle-icon port and a diamond-icon port
Each I/O module has one circle-icon port and one diamond-icon port.
In the CLI command set, the circle-icon port is called CN1 and the diamond-icon
port is called CN2. See “CLI Command Set” on page 35.
Note
SAS HBA cards are User-supplied items. They are not included
with the VTrak unit.
115200
8 N 1
Circle-icon port (CN1) LED
Diamond-icon port (CN2) LED
I/O Module Status LED

Promise Technology VTrak J310S Specifications

General

Brand	Promise Technology
Model	VTrak J310S
Category	Disk array system
Language	English
