Chapter 2: Installation
• Unpacking the VTrak (below)
• Mounting VTrak J610s in a Rack (page 11)
• Mounting VTrak J310s in a Rack (page 13)
• Installing Disk Drives (page 16)
• Setting Up Data Cable Connections (page 20)
• Setting Up Serial Cable Connections (page 27)
• Connecting the Power (page 28)
• Setting Up the CLI Connection (page 29)
Unpacking the VTrak
The VTrak J610s or J310s box contains the following items:
• VTrak J610s or J310s Unit
•Quick Start Guide
• Front bezel and key (J310s only)
• RJ11-to-DB9 serial data cable
(Units with one I/O module: 1)
(Units with two I/O modules: 2)
• 1.0m (3.3 ft) SFF-8088 4X to 4X
external SAS cable
(Units with one I/O module: 1)
(Units with two I/O modules: 2)
• Screws for disk drives
(J610s: 70, including 6 spares)
(J310s: 50, including 2 spares)
• Left and right mounting rails
• Left and right center-mount brackets
• 1.5m (4.9 ft) Power cords (2)
•CD with Product Manual and Quick
Start Guide
Warning
The electronic components within the VTrak are sensitive to
damage from Electro-Static Discharge (ESD). Observe
appropriate precautions at all times when handling the VTrak or its
subassemblies.
