Promise Technology VTrak J310S

Chapter 1: Introduction
3
Figure 3. VTrak J610s rear view
Figure 4. VTrak J310s rear view
The two external SAS ports provide the needed connectivity and bandwidth for
large capacity solutions requiring multiple JBOD boxes cascaded together while
still providing dual server support and host port failover or aggregation.
115200
8 N 1
115200
8 N 1
Cooling Unit 1
Power Supply 1
Power Supply 2
Cooling Unit 2
I/O module 2I/O module 1
O
I
O
I
115200
8 N 1
115200
8 N 1
Cooling Unit 1
Power Supply 1
Power Supply 2
I/O module 2
Cooling Unit 2
I/O module 1
