9 Power Supply
9.1 Electrical connections
Electrical specifications are indicated on model nameplate.
Typ
e
119x
-
1
-
x000
230 V ~ +/
-
10%, 11
A, 50Hz
Typ
e
119x
-
2
-
x000
230 V ~ +/
-
10%, 13
A, 60Hz
Machine tested for overvoltage category II according to IEC 1010 (EN 61010, VDE 0411).
9.2 System protection
IP 20
9.3 Power consumption
Stand-by 0.23kWh
Max. by processing 2.4 kWh
WARNING!
To lower the risk of an electrical shock, the device can only be run on a power
supply with a protective conductor.
