User Manual
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
1
Product description
1.1 Introduction
This user manual describes the special features and operational aspects of the COMPACT 2 NDT,
knowledge of which are required for efficient and effective use of the radiographic system.
Prior to working with the automated X-ray film processor COMPACT 2 NDT, it is required that the user
read the Safety Notes as well as the chapter regarding operation.
1.2 Description
The automated X-ray film processor COMPACT 2 NDT is a laboratory device used for the automatic
development of X-ray films in the non-medical field, material testing.
The device is equipped with a precise roller transport system that can process sheet films. The
automatic movie recording starts as soon as a film is entered into the feeder. The film materials are
developed, fixed, watered and dried. With the easy-to-use microprocessor control, the processing
conditions can be adapted to a wide variety of films and chemicals. The developer and fixing solutions
are regulated in their temperature, circulated and automatically regenerated.
These operating instructions give you important information on the installation, operation and
maintenance of the device. Please note the information given to ensure the reliable operation of your
COMPACT 2 NDT.
Optional accessories
Processor base stand (open) 1190-0-0010
Processor base cabinet (closed) 1190-0-0011
1.2.1 Installation
See chapter 3.
Contact information’s of persons which are qualified to make installations are request able at:
PROTEC GmbH & Co. KG
In den Dorfwiesen 14 | 71720 Oberstenfeld
Telephone: +49 (0) 7062 – 92 55 0
Fax: +49 (0) 7062 – 92 55 60
E-Mail: protec@protec-med.com
Internet: www.protec-med.com
1.3 Product specific characteristics
• Extremely high capacity
• Intermediate film rinse avoids carryover of chemicals
• Precise film surface detection for calculation of replenishment rate
• Easy modification for film exit to the light area (optional)
• Excellent image quality and consistency
1.4 Intended use
The automated X-ray film processor COMPACT 2 is intended for the automatic development of X-ray
film in the non-medical field, material testing (non-destructive radiographic tests).
The following optional accessories are available for
