COMPACT 2 NDT
User Manual
519
0
-
0
-
0002
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
64
von
65
Control panel foil
Designation hose connections
Description of the fuse
2x T / sb
10A 250V
Sticker water pressure
Sticker on the floor plate
Pull plug
Water outlet
Water outlet open
or
closed
