Specifications
Display
 Measurement Modes: Auto, R+Q, L+Q, C+D, C+R
 Equivalent Circuit: Series or Parallel
 Parameters Displayed: Value, Deviation, % Deviation or Bin Number. Deviation
and % deviation are calculated from a stored relative value
 Averaging: 2–10 Measurements
 Measurement Range: R+Q: R: 0.0001–2000 M
Q: 0.00001–50
L+Q: L: 0.0001 µH–99999 H
Q: 0.00001–50
C+D: C: 0.0001 pF–99999 µF
D: 0.00001–10
C+R: C: 0.0001 pF–99999 µF
R: 0.00001–99999 k
Test Conditions
 Test Frequency: 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz
Frequency accuracy: ±100ppm.
 Drive Voltage: Preset Levels: 0.10, 0.25, and 1.0 Vrms.
Vernier: 0.1 to 1.0 Vrms with 50 mV resolution.
 Drive level accuracy: ±2%.
 Measurement Rates: (a) Slow (2 meas./sec.), Medium (10 meas./sec.), or Fast
(20 meas./sec.) for test frequencies of 1 kHz and above.
(b) Approx. 0.6, 2.4, or 6 measurements per second at
100 Hz and 120 Hz.
 Ranging Auto or Manual
 Triggering Continuous, Manual, or Remote over RS232 or
Handler Interface
 Bias Voltage Internal: 2.0 VDC ±2%
External: 0 to +40 VDC (fused @ 0.25 A)
Accuracy
 Conditions: Allow 30 minutes of warmup before measurements; all accuracies are at
23° C (73F) ±5°C
 Basic accuracy 0.05%. Refer to the accuracy section in the Reference Manual for
detailed specifications.
 The following summarizes typical accuracy specifications:
