Protek 9216A User Manual

14
Accuracy Value
better than 1% for R > 0.125  and R < 16 M
L > 2.5 H and L < 25 kH
C > 1.25 pF and C < 12.8 mF
better than 5 % for R > 21 m and R < 96 M
L > 420 nH and L < l50 kH
C > 0.21 pF and C < 77 mF
at the following conditions:
1.0V, 0.5V, or 0.25V output voltage
Slow or medium measurement speed
Q and D < 0.1 for R and C
Q > 10 for L
100Hz, 120Hz or 1 KHz test frequency for R
100 Hz test frequency for L
max
and C
max
10 KHz test frequency for L
min
and C
min
Features and Options
General Features
Feature
Specification
Fixture
4-wire Kelvin fixture for parts with radial and axial leads
Protection
Protected up to 1 Joule of stored energy, 200 V DC for charged capacitors;
fused at 0.25 A output current for biased measurement
Zeroing
Open and short circuit compensation. Compensation Limits: short circuit:
R<20, Z<50, open circuit: Z>10k
Binning
Up to 8 Pass Bins, QDR and General Fail Bins, all defined by the front panel or
computer interface. Binning setups may be stored in nonvolatile memory
Self Test
Tests the ROM, CPU, nonvolatile RAM, clock generator, A/D converter,
internal bias, multiplier, output drive circuitry, gain circuitry, and source
resistances.
Store and Recall
memory
Stores and recalls nine complete instrument setups. Recall 0 recalls the default
setup.
RS232 Interface
All instrument functions can be controlled or read over the interface.
Operating Conditions
0 to 50°C at a relative humidity of 0 to 80%
Power
20 Watts, 110/220 VA, 50/60 Hz
Dimensions
4 ¼ " H  14 ¼ " W  15" D
Weight:
12 ¾ lbs
Warranty
Two year parts and labor on materials and workmanship
