Circuit No.
Shape (diameter length) mm
Rating
F1101
5.2 20
250 V T500 mA
250 V T250 mA
F601
5.2 20
250 V F250 mA
The internal fuse rating is as follows:
Circuit No.
Shape (diameter length) mm
Rating
Remarks
F602
5.2 20
250 V F250 mA
Note: Refer to the section on troubleshooting in the Reference Manual for instructions
on replacement of the internal fuse.
Conventions Used in This Manual
In this manual, you will find various procedures, which contain steps of instructions
for you to perform. To keep these instructions clear and consistent, this manual
uses the following conventions:
Operating procedures and names of front panel controls are in uppercase and
boldface print.
The case of each name used in the manual is the same (Initial Capitals or
UPPERCASE) as that used on the instrument itself.
Instruction steps are numbered (1, 2, 3, ), unless there is only one step.
When steps require that you make a sequence of selections using front panel
controls and keys, an arrow () is used in the text to indicate an LED result when a
front panel entry is made. Also, whether a name is a key or LED display reading is
clearly indicated:
Example: Press DISP (Entry) ENTER
Safety Terms
The following terms are also used in this manual:
WARNING identifies conditions or practices that could result in injury.
CAUTION identifies conditions or practices that could result in damage to this
product or other property.
NOTICE identifies conditions or practices that could result in incorrect test
data.
