Multipoint and Quickbridge - Hardware Installation Guide 10
• Ethernet Port supports the following features:
1. Auto MDI-X, auto configuration and fixed speed/duplex configurations.
2. Jumbo frames of size up to 9 k bytes.
3.1.2 Grounding Points
To protect the device against lighting or ESD events, you must ground the device properly. To ensure proper grounding, use
the ground point that is situated at the bottom corner of the device and the grounding screw (M4 thread size) provided to
attach a ground wire of at least 12 AWG stranded to the device.
Recommended Ethernet Cable Specifications
Type
Cat5e, Cat6, STP, 24 AWG, UL rated, Shielded, UV Resistant and outdoor-rated
Impedance 100 ohms
Cable Length 330 feet / 100 meters
: The total length of cabling between the Personal Computer and the device cannot
exceed 100 meters (includes cable from the Personal Computer to the PoE, and the
cable from the PoE to the device). Due to DC power requirements, the maximum cable
length between the PoE Injector and the device should be less than 100 meters.
